Micro Drone Camera 600TVL CMOS PAL FPV Cam

Description

FPV HD Drone Camera Fully assembled
Ready to use
No need of wiring or soldering
Simple plug and play
Best with Arduino

SPECIFICATIONS OF FPV HD Drone Camera:

• Resolution: 600 TVL 1280 * 960
• Camera Dimensions: 12.5mm * 12.5mm * 17mm
• Illumination: 0.5LUX
• Format:PAL / NTSC
• Power supply: 5V 100mA
• Audio Lens: Wide-angle 1.8mm (170 degree)
• Image sensor:1/4 CMOS image sensor
• Sensitive area: 3.5964mm x 2.7084mm
• 648 pixels (horizontal) × 488 (vertical) 648 (horizontal) × 488 (vertical)
• Scanning Frequency Horizontal: 15.625KHz
• Vertical: 50Hz
• level: 15.7343KHz
• Vertical: 60Hz
• Electronic Shutter 1 / 50-1 / 80000 (sec) 1 / 60-1 / 80000 (sec)
• SNR ≥48dB (AGC OFF)
• Minimum illumination : 0.1 Lux / F1.2
• Composite video signal :1.0Vp-p 75Ω
• Standard Lens :1.8 mm
• Specifications PCB: 20mm*20mm
• Power: DC5V ± 10% 70mA ± 10%
• Operating temperature :-10 ℃ ~ 60 ℃ RH95% Max

Features:

• The 1/4 1.8mm Micro CMOS FPV camera with 170° Wide Angle Lens is the perfect option for FPV!
• It’s incredibly small, lightweight, and is easy to mount.
• The small size also make the mounting options nearly limitless

Package Includes:

1 X 600TVL Wide Angle Lens Camera
