BLHELI ESC 50A for Brushless Motor

BLHeli ESC 50A 2S-6S multirotor drone brushless speed control in Pakistan

4,100 ₨

25 in stock

SKU: EMAX-ESC-50A Category: Tags: , , , ,

Description

Features:
BLHELI ESC 50A for Brushless Motor Based on BLHeli firmware, further optimized to the perfect drive performance.
Low-voltage protection, over-heat protection and throttle signal loss protection.
Separate power supply for MCU and BEC, enhancing the ESC’s ability of eliminating magnetic interference.
Parameters of the ESC can be set via program card or transmitter.
Throttle range can be set to be compatible with different receivers.
Equipped with built-in linear BEC or switch BEC BLHELI ESC 50A for Brushless Motor
Max speed: 210,000 rpm for 2-pole, 70,000 rpm for 6-pole, 35,000 rpm for 12-pole.
– Support Oneshot125,Oneshot42,Mutishot and at least Dshot1200 and at least Proshot1000 etc.
– Main IC:runs on an ARM 32bit MCU,running at 48MHz
– MOS:Both low and high side fets are Nfets,switch open-close very fast
– Programmable pwm frequency, up to 48kHz,run motors even smoother
– Low voltage ,temperature and current protection
– New telemetry function

– BLHeli-32 Bootloader & Firmware

Brand Name: FVT
Input Voltage: 3-6S Lipo
Emax FIRMWARE WITH BEL-HELI BRAND ESC
Specification:
Brand Name: FVT
Model: CloundPhoenix 50A
Item Name: 50A BLheli_32 2-6S Brushless ESC
Input Voltage: 3-6S Lipo
Con. Current: 50A
Peak Current: 55A (10S)
Firmware: BLheli_32
BEC: NO
Size: 35x17mm
Weight: 14g

Features:

– Support Oneshot125,Oneshot42,Mutishot and at least Dshot1200 and at least Proshot1000 etc.
– Main IC:runs on an ARM 32bit MCU,running at 48MHz
– MOS:Both low and high side fets are Nfets,switch open-close very fast
– Programmable pwm frequency, up to 48kHz,run motors even smoother
– Low voltage ,temperature and current protection
– New telemetry function

– BLHeli-32 Bootloader & Firmware

Package Included:
1x 50A BL_32 ESC

Package Included:
1 x Emax FIRMWARE WITH BEL-HELI BRAND ESC
